Dexter Laundry V-Series Service Procedures And Parts Data

64
WCVD-18
Torque
Qty. Bolt Size Socket Location (Ft Lbs)
1 1/2-13 x 2 1/2" 3/4" Hex Front Mtg. Clamp Ring Ends 20-30
4 1/2-13 x 1 1/4" 3/4" Hex Front and Rear Mtg. Rings to Base 70-110
12 3/8-16 x 2" 9/16" Hex Tub Back Ring to Tub Back 45-80
6 1/2-13 x 1 1/2" 15/16" Hex Brg Hsg to Tub Back 70-110
6 3/8-16 x 1 3/4" 9/16" Hex Brg Hsg, Pulley End 45-80
1 1/2-13 x 1 1/4" 3/4" Hex Hub of Driven Pulley 70-110
2 5/16-18 x 7/8" 5/16" Square Drive Pulley Set Screws 190-200 In/Lb
WCVD-25
Torque
Qty. Bolt Size Socket Location (Ft Lbs)
1 1/2-13 x 2 1/2" 3/4 Hex Front Mtg. Clamp Ring Ends 30-40
4 1/2-13 x 1 1/4" 3/4 Hex Front and Rear Mtg. Rings to Base Assy. 70-110
12 3/8-16 x 2" 9/16 Hex Tub Back Ring to Tub Back 45-80
6 1/2-13 x 1 1/2" 15/16 Hex Brg Hsg to Tub Back 70-110
6 3/8-16 x 1 3/4" 9/16 Hex Brg Hsg, Pulley End 45-80
1 1/2-13 x 1 1/4" 3/4" Hex Hub of Driven Pulley 70-110
2 5/16-18 x 7/8" 5/16" Square Drive Pulley Set Screws 190-200 In/Lb
WCVD-40
Torque
Qty. Bolt Size Socket Location (Ft Lbs)
1 5/8-11 x 3" 15/16" Hex Front Mtg. Clamp Ring Ends 60-80
4 5/8-11 x 1 1/2" 15/16" Hex Front and Rear Mtg. Rings to Base Assy 120-150
12 7/16-14 x 1 1/2" 11/16" Hex Tub Back Ring to Tub Back 100-125
6 5/8-11 x 1 1/2" 15/16" Hex Brg Hsg to Tub Back 120-150
6 7/16-14 x 2" 11/16" Hex Brg Hsg, Pulley End 100-125
1 5/8-11 x 1 1/2" 15/16" Hex Hub of Driven Pulley 120-150 In/Lb
2 5/16-18 x 7/8" 5/16" Square Drive Pulley Set Screws 190-200 In/Lb
WCVD-55
Torque
Qty. Bolt Size Socket Location (Ft Lbs)
1 1/2-13 x 2" 3/4" Hex Front Mtg. Clamp Ring Ends 30-40
1 3/8-16 x 3" 5/16" Allen Front Clamp Ring 100 In/Lb
2 1/2-13 x 2" 3/4" Hex Tub to Base Assy 70-110
6 7/16-14 x 1" 9/16" Hex Brg Hsg to Tub Back 60-80
6 3/4-10 x 3" 1 1/8" Hex Brg Hsg to Base Assy 200-300
3 7/16-14 x 1" 9/16" Hex Hub of Driven Pulley 28-32
3 1/4-20 x 1" 3/16" Allen Drive Pulley Set Screws 80 In/Lb
WCVD-75
Torque
Qty. Bolt Size Socket Location (Ft Lbs)
1 1/2-13 x 2" 3/4" Hex Front Mtg. Clamp Ring Ends 30-40
1 3/8-16 x 3" 5/16" Allen Front Clamp Ring 100 In/Lb
2 1/2-13 x 2" 3/4" Hex Tub to Base Assy 70-110
6 7/16-14 x 1" 9/16" Hex Brg Hsg to Tub Back 60-80
6 3/4-10 x 3" 1 1/8" Hex Brg Hsg to Base Assy 200-300
3 7/16-14 x 1" 9/16" Hex Hub of Driven Pulley 28-32
3 1/4-20 x 1" 3/16" Allen Drive Pulley Set Screws 80 In/Lb
