58
PHOTO # 1 SHOWS THE
DOOR CAM AWAY FROM
DOOR LOCK ASSEMBLY
PHOTO # 2
SHOWS WHERE YOU
WANT CLEARANCE
PHOTO #4
SHOWS SWITCH SWIVELLING FOR
ADJUSTMENT WITH GUAGE IN.
PHOTO # 3 SHOWS
GUAGE IN PLACE
FOR ADJUSTMENT
