Dexter Laundry WCN40AA - T-400 Bolt Torque Chart; T-600 Bolt Torque Chart

T-600 Bolt Torque Chart
Bolt Size Where Used Torque
1/2-13 x 2 1/2" Frt Ring Ends - Belly Band 30-40
5/8-11 x 1 1/2" Front/Rear Mtg Ring to Base 120 -150
7/16-14 x 2" Rear Mtg Ring to Tub Back 100-125
5/8-11 x 1 1/2" Brg Hsg to Tub Back 120 -150
7/16-14 x 1 1/2" Brg Hsg - Pulley End 100-125
5/8-11 x 1 1/2" Hub of Driven Pulley 100-125
5/16-18 x 7/8" Drive Pulley Set Screws (Loctite) 190-200
T-400 Bolt Torque Chart
Bolt Size Where Used Torque
1/2-13 x 2 1/2" Frt Ring Ends - Belly Band 30-40
5/8-11 x 1 1/2" Front/Rear Mtg Ring to Base 120 -150
7/16-14 x 2" Rear Mtg Ring to Tub Back 100-125
1/2-13 x 1 1/4" Brg Hsg to Tub Back 70-110
3/8-16 x 1 1/2" Brg Hsg - Pulley End 45-80
1/2-13 x 1 1/4" Hub of Driven Pulley 45-80
5/16-18 x 7/8" Drive Pulley Set Screws (Loctite) 190-200
55
54 55
Part # 8533-035-002 4/22 Part # 8533-035-002 4/22
