Dexter Laundry WCN40AA - Section 6: Parts Data

Models
WCN25AA
WCN25AB
WCN40AA
WCN40AB
Wiring Harness Part # by Model
Key Description WCN25AA WCN25AB WCN40AA WCN40AB QTY
Use Following Items with Timer Part Number 9571-359-002
* Wiring Harness, Main 9627-680-002 9627-680-002 9627-680-002 9627-680-002 1
* Wiring Harness, Control 9627-681-003 9627-681-003 9627-681-003 9627-681-003 1
* Wiring Harness, Coin accumulator 9627-682-001 9627-682-001 9627-682-001 9627-682-001 1
* Wiring Harness, Drain Valve 9627-683-001 9627-683-001 9627-683-001 9627-683-001 1
* Clamp, Cable- 1/4 Dia 8654-125-001 8654-125-001 8654-125-001 8654-125-001 1
* Connector, Clear In-Line 8653-074-001 8653-074-001 8653-074-001 8653-074-001 1
Use Following Items with Timer Part Number 9571-362-001
* Wiring Harness, Drain Valve 9627-683-001 9627-683-001 9627-683-001 9627-683-001 1
* Wiring Harness, Control 9627-689-001 9627-689-001 9627-689-001 9627-689-001 1
* Wiring Harness, Main 9627-695-001 9627-695-001 9627-695-001 9627-695-001 1
* Wiring Harness, Countdown 9627-708-001 9627-708-001 9627-708-001 9627-708-001 1
* Wiring Harness, Coin Accumulator 9627-682-001 9627-682-001 9627-682-001 9627-682-001 1
