Dexter Laundry WCN40AA User Manual

Specications for below models
are outlined in this book:
WCN25AA 2220-240 volts 60hz. Single Phase
WCN25AB 208-240 volts 60hz. Three Phase
WCN40AA 220-240 volts 60hz. Single Phase
WCN40AB 208-240 volts 60hz. Three Phase
Cycle
Times
Prewash & 3
Rinses
Prewash & 2
Rinses
No Prewash &
3 Rinses
No Prewash &
2 Rinses
Preswash 4 minutes 4 minutes Not Used Not Used
Drain 40 seconds 40 seconds Not Used Not Used
Wash 8 minutes 8 minutes 8 minutes 8 minutes
Drain 40 seconds 40 seconds 40 seconds 40 seconds
Rinse 1 3 min. 45 sec. Not Used 3 min. 45 sec. Not Used
Drain 40 seconds Not Used 40 seconds Not Used
Rinse 2 3 min. 45 sec. 3 min. 45 sec. 3 min. 45 sec. 3 min. 45 sec.
Drain 40 seconds 40 seconds 40 seconds 40 seconds
Int. Spin 50 seconds 50 seconds 50 seconds 50 seconds
Rinse 3 3 min. 45 sec. 3 min. 45 sec. 3 min. 45 sec. 3 min. 45 sec.
Drain 40 seconds 40 seconds 40 seconds 40 seconds
Extract 4 minutes 4 minutes 4 miinutes 4 minutes
Tumble 16 seconds 16 seconds 16 seconds 16 seconds
Tot al* 32 minutes 27.5 minutes 27 minutes 23 minutes
*Cycle times are approximate.
Water Usage
(T-400)
Wash & 2
Rinses
Prewash & 2
Rinses
Wash & 3
Rinses
Prewash & 3
Rinses
Preswash Not Used 13.9 gallons Not Used 13.9 gallons
Wash 15.3 gallons 10.6 gallons 15.3 gallons 10.6 gallons
Rinse 1 Not Used Not Used 10.3 gallons 10.3 gallons
Rinse 2 10.2 gallons 10.2 gallons 10.2 gallons 10.2 gallons
Int. Spin
Rinse 3 13.35 gallons 13.35 gallons 13.35 gallons 13.35 gallons
Tot al 38.85 gallons 48.05 gallons 49.15 gallons 58.35 gallons
Water Usage
(T-600)
Wash & 2
Rinses
Prewash & 2
Rinses
Wash & 3
Rinses
Prewash & 3
Rinses
Preswash Not Used 19.5 gallons Not Used 19.5 gallons
Wash 21.1 gallons 13.3 gallons 21.1 gallons 13.3 gallons
Rinse 1 Not Used Not Used 12.6 gallons 12.6 gallons
Rinse 2 12.2 gallons 12.2 gallons 12.2 gallons 12.2 gallons
Int. Spin
Rinse 3 17.85 gallons 17.85 gallons 17.85 gallons 17.85 gallons
Tot al 51.15 gallons 62.85 gallons 63.75 gallons 75.45 gallons
Water Temp
Heavy Duty Normal Perm Press Delicates
Preswash Hot Warm Warm Cold
Wash Hot Warm Warm Cold
Rinse 1 Cold Cold Cold Cold
Rinse 2 Cold Cold Cold Cold
Rinse 3 Cold Cold Cold Cold
15
Part # 8533-035-002 4/22
14
Part # 8533-035-002 4/22
Section 1:
Machine
Mounting
Machine
Mounting
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring
Parts
Data
