Dexter Laundry WCN40AA User Manual

Specications
T-400 Coin Washer
Capacity 25lbs.
Dimensions
Cylinder Depth 14 1/8”
Cylinder Diameter 25”
Cylinder Volume (cubic feet) 4.0
Door Opening 15 1/4”
Door Height (oor to bottom of
door)
16 1/2”
Overall Height 48 1/4”
Cabinet Width 29 7/8”
Overall Depth 27 1/8”
Drain Diameter (O.D.) 3”
Drain Height (oor to center of
outlet)
5”
Recommended Clearance Be-
tween Machines (min)
1/2”
Necessary Service Clearance
Behind Machine
24”
Cylinder RPM
Tumble Speed 50
Extract Speed 510
Extract Speed G-Force 92
Cylinder Direction in Extract Counter-clockwise
Motor H.P.
Wash Single Phase 0.35
Wash Three Phase 0.35
Extract Single Phase 1.5
Extract Three Phase 1.5
Amperage (avg. measured on L1)
Wash Single Phase 3.75
Wash Three Phase 3.5
Extract Single Phase 3
Extract Three Phase 8.5
Running Amps (Maximum)
Single Phase 13
Three Phase 6.2
Circuit Breaker (Amps)
Single Phase 20
Three Phase 15
Built-in Controls Circuit Breaker Yes
Built in Motor Protection Yes
Voltage 60Hz.
Single Phase 220-240
Three Phase 208-240
Service
Single Phase 3 wires + ground
Three Phase 3 wires + ground
Wire Size (Minimum)
Single Phase 12
Three Phase 12
Water
Avg. Water Usage
Normal Cycle with Full
Load
39 gallons
Max Hot Water Usage
Hot Cycle with Full Load
15 gallons
Recommended Hot Water
(degrees)
140
Water Pressure (min/max) 30-120psi
Water Inlet Size (hose
thread)
3/4”
Water Flow Rate (gallons/
minute)
9
Wash Cycle
Normal Wash-Including Fill
Time
23 minutes
Wash Temperatures Hot, Warm, &
Cold
Rinse Temperatures Cold-Std;
Warm-Opt
Mounting Hole Dimensions
Left to Right 26 7/8”
Front to Cabinet to First
Hole
2 1/2”
First Hole to Second Hole 14 1/2” or 17 1/8”
Second Hole to Third Hole N/A
Mounting Bolt Diameter 1/2” or 5/8”
Hole Diameter in Base 3/4”
Concrete Thickness (min) 6”
Recommended Mounting
Height
4” to 6”
Weight
Shipping (lbs.) 503/1p 495/3p
Net (lbs.) 485/1p 477/3p
Specications
T-600 Coin Washer
Capacity 40lbs.
Dimensions
Cylinder Depth 21 1/8”
Cylinder Diameter 25”
Cylinder Volume (cubic feet) 6.0
Door Opening 15 1/4”
Door Height (oor to bottom of
door)
16”
Overall Height 49 3/4”
Cabinet Width 29 7/8”
Overall Depth 35 7/8”
Drain Diameter (O.D.) 3”
Drain Height (oor to center of
outlet)
5”
Recommended Clearance Be-
tween Machines (min)
1/2”
Necessary Service Clearance
Behind Machine
24”
Cylinder RPM
Tumble Speed 50
Extract Speed 510
Extract Speed G-Force 92
Cylinder Direction in Extract Counter-clockwise
Motor H.P.
Wash Single Phase 0.4
Wash Three Phase 0.35
Extract Single Phase 1.8
Extract Three Phase 1.5
Amperage (avg. measured on L1)
Wash Single Phase 3.75
Wash Three Phase 3.5
Extract Single Phase 3
Extract Three Phase 5.25
Running Amps (Maximum)
Single Phase 13
Three Phase 6.2
Circuit Breaker (Amps)
Single Phase 20
Three Phase 15
Built-in Controls Circuit Breaker Yes
Built in Motor Protection Yes
Voltage 60Hz.
Single Phase 220-240
Three Phase 208-240
Service
Single Phase 3 wires + ground
Three Phase 3 wires + ground
Wire Size (Minimum)
Single Phase 12
Three Phase 12
Water
Avg. Water Usage
Normal Cycle with Full
Load
51 gallons
Max Hot Water Usage
Hot Cycle with Full Load
21 gallons
Recommended Hot Water
(degrees)
140
Water Pressure (min/max) 30-120psi
Water Inlet Size (hose
thread)
3/4”
Water Flow Rate (gallons/
minute)
9
Wash Cycle
Normal Wash-Including Fill
Time
23 minutes
Wash Temperatures Hot, Warm, &
Cold
Rinse Temperatures Cold-Std;
Warm-Opt
Mounting Hole Dimensions
Left to Right 26 7/8”
Front to Cabinet to First
Hole
2 3/4”
First Hole to Second Hole 21 1/2”
Second Hole to Third Hole N/A
Mounting Bolt Diameter 5/8”
Hole Diameter in Base 3/4”
Concrete Thickness (min) 6”
Recommended Mounting
Height
4” to 6”
Weight
Shipping (lbs.) 680/1p 652/3p
Net (lbs.) 655/1p 627/3p
16 17
Part # 8533-035-002 4/22 Part # 8533-035-002 4/22
