Chapter 2 Hardware Installation
Chapter 2
I/O Connectors
TheSerialATAconnectorsareusedtoconnectSerialATAdevices.ConnectoneendoftheSe-
rialATAcabletoaSATAconnectorandtheotherendtoyourSerialATAdevice.
BIOS Setting
ConfiguretheSerialATAdrivesintheAdvancedmenu(“SATAConfiguration”submenu)ofthe
BIOS.Refertochapter3formoreinformation.
SATA (Serial ATA) Connectors
SATA2.03Gb/s
• 4SerialATAports
-2SATA2portswithdatatransferrateupto3Gb/s
7
RXN
GND
TXP
TXN
GND
1
RXP
GND
Features
SATA 0
SATA 1
SATA 4
SATA 5
BIOS Setting
ConfiguretheonboardaudiointheChipsetmenu(“SouthBridge”submenu)oftheBIOS.
Refertochapter3formoreinformation.
Driver Installation
Installtheaudiodriver.Refertochapter4formoreinformation.
