Chapter 2 Hardware Installation
Chapter 2
Thelithiumionbatterypowersthereal-timeclockandCMOSmemory.Itisanauxiliarysource
ofpowerwhenthemainpowerisshutoff.
Safety Measures
•Dangerofexplosionifbatteryincorrectlyreplaced.
•Replaceonlywiththesameorequivalenttyperecommendbythemanufacturer.
•Disposeofusedbatteriesaccordingtolocalordinance.
Battery
Battery
SDVO Connector
SDVO
2
1
30
29
TheSDVOconnectorisusedtoconnecttheoptionalSDVO-LVDSdaughterboard.
Pins Pin Assignment Pins Pin Assignment
1
Ground 2 DPB_AUXP
3
DPB_LANE0_P 4 DPB_AUXN
5
DPB_LANE0_N 6 SDVO_STALLP
7
Ground 8 SDVO_STALLN
9
DPB_LANE1_P 10 SDVO_INTP
11
DPB_LANE1_N 12 SDVO_INTN
13
Ground 14 PCIE_RST
15
DPB_LANE2_P 16 DPB_CTRLCLK
17
DPB_LANE2_N 18 DPB_CTRLDATA
19
Ground 20 DPB_HPD
21
DPB_LANE3_P 22 GPIO15/SMBCLK
23
DPB_LANE3_N 24 GPIO27/SMBDATA/L_BKLTCTL
25
+3V3 26 +3V3
27
+5V 28 +5V
29
+12V 30 +12V
