24
Chapter 2 Hardware Installation
Chapter 2
The8-bitDigitalI/Oconnectorprovidespowering-onfunctiontoexternaldevicesthatarecon-
nectedtotheseconnectors.
1
4
+12V
Ground
5VSB
+5V
DigitalI/Opower
DigitalI/O
Digital I/O Connector
Digital I/O Power Connector
Digital I/O Connector
Pins Function
1
DIO7
2
DIO6
3
DIO5
4
DIO4
5
DIO3
6
DIO2
7
DIO1
8
DIO0
18
Theamplifyconnectorwhichhasamplifyingfeatureisusedtoconnectexternalspeakers.Us-
ingthesamesignalcabletoconnectwithexternalspeaker.
Amplify
Amplify Connector
OutL+
OutR+
OutL-
OutR-
1
4
