Chapter 2 Hardware Installation
Chapter 2
SDVO-LVDS Daughterboard (optional)
Features
• ChrontelCH7308B
• Supports18/24-bit1600x1200LVDSpanel(default1280x1024)
• 1LVDSLCDpanelconnector
• 1LCD/Inverterpowerconnector
• SDVOinterface
• SupportsdimmingcontrolviahotkeysorAPtool
Dimensions
• 45mm(1.77")x38mm(1.49")
JP8
3-4On:+5V
1
3
5
2
4
6
1
3
5
2
4
6
5-6On:+3.3V
(default)
1-2On:+12V
1
3
5
2
4
6
JP8isusedtoselectthepowersuppliedtotheLCDpanel.
Power Select for the LCD Panel
Important:
Beforepowering-onthesystem,makesureJP8’ssettingmatchestheLCDpanel’s
specification.SelectingtheincorrectvoltagewillseriouslydamagetheLCDpanel.
