Chapter 2 Hardware Installation
Chapter 2
Front Panel Connector
HDD-LED - HDD LED
ThisLEDwilllightwhentheharddriveisbeingaccessed.
RESET SW - Reset Switch
Thisswitchallowsyoutorebootwithouthavingtopoweroffthesystem.
PWR-BTN - Power Switch
Thisswitchisusedtopoweronoroffthesystem.
PWR-LED - Power/Standby LED
Whenthesystem’spowerison,thisLEDwilllight.WhenthesystemisintheS1(POS-Power
OnSuspend)state,itwillblinkeverysecond.WhenthesystemisintheS3(STR-SuspendTo
RAM)state,itwillblinkevery4seconds.
HDD-LED
RESET-SW
PWR-LED
PWR-BTN
12
11
21
Pin Pin Assignment Pin Pin Assignment
HDD-LED
3 HDDPower
PWR-LED
2 LEDPower
5 Signal 4 LEDPower
RESET SW
7 Ground 6 Signal
9 RSTSignal PWR-BTN 8 Ground
11 N.C. 10 Signal
Expansion Slots
PCI Express x16 Slot
InstallPCIExpressx16graphicscard,thatcomplytothePCIExpressspecifications,intothe
PCIExpressx16slot.Toinstallagraphicscardintothex16slot,alignthegraphicscardabove
theslotthenpressitdownfirmlyuntilitiscompletelyseatedintheslot.Theretainingclipof
theslotwillautomaticallyholdthegraphicscardinplace.
Mini PCIe Slot
TheMiniPCIesocketisusedtoinstallahalfsizeMiniPCIecard.MiniPCIecardisasmall
formfactorPCIcardwiththesamesignalprotocol,electricaldefinitions,andconfiguration
definitionsastheconventionalPCI.ItsupportsPCIeandUSBsignals.TheMiniPCIeslotdoes
notsupportmSATA.
PCIExpressx16
MiniPCIExpress
