Diamondview DV55RM5 - Page 46

46
Main Item
Control Item
CMD
Type
Value/Reply
(Decimal)
Value/Reply
(HEX)
Content
CMD
(HEX)
Remark
12
0C
DISPLAYPORT1 Key
18
12
SOURCE Key
19
13
P
-SOURCE Key
20
14
PIP Key
21
15
P
-POSITION Key
22
16
SWAP Key
23
17
SCALING Key
26
1A
BRIGHT Key
27
1B
CONTRAST Key
33
21
OPS Key
ALL W 0
00
Reset all
41 4C 4C
KLC W/R
0
00
Un
-lock keys
4B 4C 43
1
01
Lock keys
SER R 13 bytes
13 bytes
Read Serial Number
53 45 52
MNA R 13 bytes
13 bytes
Read Model Name
4D 4E 41
GVE R 6 bytes
6 bytes
Read Firmware Version
47 56 45
RTV R 0~255
00~FF
Read RS232 table
Version
52 54 56
RTT R 0~255
00~FF
Read the temperature of
the internal thermal
sensor. (- 128 ~ +127 )
52 54 54
RSF
R 0~255
00~FF
Read the Fan 1 speed.
(RPM
= 30 x Reply Value)
52 53 46
W 0/0~255
00/00~FF
Read the Fan 1 speed.
(RPM=30 x Reply
Value).
W 1/0~255
01/00~FF
Read the Fan 2 speed.
(RPM=30 x Reply
Value).
Multi-
Display
SID W 0
00
Show Monitor ID
53 49 44
CID W 1~100
01~64
Chang Monitor ID
43 49 44
Note 1
