47
Main Item
Control Item
CMD
Type
Value/Reply
(Decimal)
Value/Reply
(HEX)
Content
CMD
(HEX)
Remark
VW
S
W/R
0
00
Video Wall Switch Off
56 57 53
1
01
Video Wall Switch On
VW
F
W/R
0
00
Video Wall Frameless
Off
56 57 46
1
01
Video Wall Frameless
On
MAT W/R
X : 1~10 Y :
1~10
X: 01~0A Y:
01~0A
Matrix X, Y value
High quarter is X : 7 ~ 4
bit Low quarter is Y : 3 ~
0 bit
4D 41 54
DIV W/R
X :
1~10 Y :
1~10
X: 01~0A Y:
01~0A
Divisions X, Y value
High quarter is X : 7 ~ 4
bit Low quarter is Y : 3 ~
0 bit
44 49 56
Note 2
POD W/R 0~30
00~1E
Integral part of Power On
Delay (0, 1, 2, …, 30
sec).
50 4F 44
POE W/R 0~19
00~13
Fractional part of Power
On Delay (0, 0.05,
0.10, …, 0.95
sec).
50 4F 45
Configuratio
n Presets
PSS W 0~127
00~7F
XX-th Preset
Configurations Save
50 53 53
PSR W 0~127
00~7F
XX-th Preset
Configurations Recall
50 53 52
PSH W 0~127
00~7F
Check if XX-th
Configurations is valid
(return
1) or not (return 0)
50 53 48
Self-
Diagnosis
OTT R 4 bytes
4 bytes
Accumulated operation
time (minutes)
4F 54 54
Note 5
OTS R 4 bytes
4 bytes
Operation time (minutes)
4F 54 53
Note 5
ERR R 4 bytes
4 bytes
Error code
45 52 52
Note 4
LMT R 8 bytes
8 bytes
The maximum
temperature and the
corresponding
accumulated operation
time
(minutes)
4C 4D 54
Note 6
LM1 R 8 bytes
8 bytes
The 1st error log
4C 4D 31
Note 7
LM2 R 8 bytes
8 bytes
The 2nd
error log
4C 4D 32
Note 7
