M I N I - C U B E – U S E R M A N U A L
Rev 1.3 06/2018 20/59
Setup
For normal safety requirements and given the type of examination it performs, the
instrument must be positioned away from heat sources, in areas unreachable by
liquids and in a dust-free environment. Position the instrument on a solid perfectly
level bench, not subject to shaking or vibrations. The 15 cm or 6” perimeter
distance as indicated in the figure 3.3 must be observed as a safety precaution.
It is advisable to position the instrument to 1 meter from devices that
generate electromagnetic waves (e.g. laboratory fridges, centrifuges) and
instruments that do not have CE marking.
The safety of the instrument and of the operator is not guaranteed if one or more
of the following conditions are violated.
- The mains must be compatible with the voltage and current
specifications indicated on the metal plate affixed below the
instrument.
- Before connecting external accessories (BC reader, printer, USB
sticks), check the compatibility.
Installation procedure
Only use the power supply unit provided
1. Position the instrument on a solid surface, as described above.
2. After checking that the power switch is in the “OFF” position, connect the
power supply unit plug provided with the instrument.
3. Connect the power supply unit cable to the mains.
4. Optional - connect the barcode scanner and Bluetooth printer. Once the
MINI-CUBE is powered on, a series of beeps will be heard indicating that
