M I N I - C U B E – U S E R M A N U A L
23/59 Rev 1.3 06/2018
Test tube labelling
The MINI-CUBE can accept sample tubes with a maximum of 1 secondary
label adhered as close to the lavender EDTA cap as possible and with a
label-free gap one side. As the samples are loaded, it is important to align the
label-free gap with the dot on the insertion ring so the label-free gap is
towards the right of the analyzer (fig. 4.0).
Fig 4.0
