BARCODE: ASCII string with variable lengths, maximum of 15
characters allowed. This is the barcode just as it is read
by the Mini Cube Barcode Reader.
TERMINATOR: the string of barcodes terminates with the 0x10 byte. This
is because the length of this string is variable.
DATA ANALYSES : string of 6 characters without terminator,
“DDMMYY” where:
“DD” = day of the month, from “01” to “31” ASCII.
“MM” = Month of the year, from “01” to “12” ASCII.
“YY” = Year of the century, from “00” to “99” ASCII.
TIME ANALYSES : string of 4 characters without terminator, “hhmm”
where:
“hh” = hour of the day, from “00” to “23” ASCII.
“mm” = Minutes, from “00” to “59” ASCII.
VES: Value of the VES measured, ASCII string without terminator: from “
0” (3 spaces + ‘0’) transmitted in the case of an error, to “ 140” (1
space + “140”). If the result is greater of 140 the string will be “>140”.
EXAMPLES, see following table:
