DIG 710A Series - Page 5

Anti-siphon valve
14. Anti-siphon cap
15. 3/4″ or 1″ pipe thread outlet (FNPT)
16. Manual flow control knob
17. External bleed screw
18 3/4″ or 1″ pipe thread inlet (FNPT)
Manual valve actuator
20. Manual flow control knob
21. External bleed screw
22. 3/4″ adapter
23. 3/4″ seat washer
24. 3/4″ washer
25. 1″ adapter
26. Seat washer
27. 1″ washer
j
k
g
h
l
2)
2!
2@
2#
;
2$
2%
2^
2&
3
