Digi Connect ME

Connectors and Blocks
32
Module JTAG Interface Connector
Pin Assignments
JTAG Signal ME JTAG pin # JTAG Connector (P11) pin #
+3.3V 1 2
GND 2 1
TRST# 3 4
GND 4 3
TDI 5 6
GND 6 5
TMS 7 8
GND 8 7
TCK 9 10
RXD 10 9
TDO 11 12
SRST 12 11
+3.3V 13 14
TXD 14 13
