Digi Connect ME Hardware Reference

Revision J
79
Revision J
 Updated the recommended PCB layout image.
 Changed all mentions of “JTag” to “JTAG.”
 Corrected the V
IL
Max value within the Inputs table of the DC Characteristics section in
Appendix A.
 Improved the quality of the PoE Power Supply schematic in Appendix C.
 Added Digi Connect ME 9210 Declaration of Conformity information to Appendix B.
 Added revised front view and side view images of the Digi Connect ME and Digi Connect
Wi-ME modules to Appendix A.
Revision I
This revision letter is not used in order to avoid confusion with other letters/numbers which it
resembles.
Revision H
 Corrected bookmarks for pdf file.
 Correct pin numbering on the JTAG Debugger Connector Pin Orientation image.
 Added missing Digi Connect ME part numbers.
 Added section describing the JTAG Jumper and new accompanying image.
 Made several corrections and clarifications to the guide per a red lined print copy from BIll
Kumpf.
Revision G
 Added CAN Bus information.
Revision F
 Added Digi Connect ME sketch to Thermal Specifications.
 Added antenna configurations.

Digi Connect ME Specifications

General

Brand	Digi
Model	Connect ME
Category	Network Hardware
Language	English
