Digi Connect ME Hardware Reference

Revision E
80
Revision E
Changed schematics in appendix A to reflect correct measurements.
Revision D
Added a new section labeled “Thermal Specifications” to the book. This section outlines the
temperature ranges at which the devices specified can still function properly.
Revision C
 Updates to schematics in Chapter 2.
 Added/revised Module Pin-out table in Chapter 3.
 Updated GPIO tables throughout book.
Revision B
 Fixed page numbers to make them correspond in PDF form.
 Added components to Development Board schematics. (#19 and 20)
Revision 90000631_G>90000897_A
 Added Digi Connect ME 9210 related information.
 Updated schematics in development board chapter to reflect 9210 changes.

Digi Connect ME Specifications

General

Power Supply	3.3 VDC
Ethernet Ports	1
Serial Ports	1
Network Interface	10/100Base-T Ethernet
Serial Interface	RS-232/485
Operating Temperature	-40°C to 85°C
Product Type	Embedded Device Server
Protocols	TCP/IP, UDP, HTTP, FTP, SMTP, DHCP, DNS, SNMP, Telnet
