AT commands I/O settings commands

Digi XBee® 3 Cellular LTE Cat 1 AT&T Smart Modem User Guide

205

Parameter Description

0 Disabled

1 SPI_MOSI

2 N/A

3 Digital input

4 Digital output, default low

5 Digital output, default high

Default

D5 (DIO5/ASSOCIATED_INDICATOR)

Sets or displays the DIO5/ASSOCIATED_INDICATOR configuration (pin 15).

Parameter range

0, 1, 3 - 5

Parameter Description

0 Disabled

1 Associated LED

2 N/A

3 Digital input

4 Digital output, default low

5 Digital output, default high

Default

D6 (DIO6/RTS)

Sets or displays the DIO6/RTS configuration (pin 16).

Parameter range

0, 1, 3 - 5

Parameter Description

0 Disabled

RTS flow control

Default Chapter2
