AT commands I/O settings commands

Digi XBee® 3 Cellular LTE Cat 1 AT&T Smart Modem User Guide

206

Parameter Description

2 N/A

3 Digital input

4 Digital output, default low

5 Digital output, default high

Default

D7 (DIO7/CTS)

Sets or displays the DIO7/CTS configuration (pin 12).

Parameter range

0, 1, 3 - 5

Parameter Description

0 Disabled

CTSflow control

2 N/A

3 Digital input

4 Digital output, default low

5 Digital output, default high

Default

0x1

D8 (DIO8/SLEEP_REQUEST)

Sets or displays the DIO8/DTR/SLP_RQ configuration (pin 9).

Parameter range

0, 1, 3 - 5

Parameter Description

0 Disabled

1 SLEEP_REQUEST input

3 Digital input

4 Digital output, default low

5 Digital output, default high

Default Chapter2
