AT commands I/O settings commands

Digi XBee® 3 Cellular LTE Cat 1 AT&T Smart Modem User Guide

207

Default

D9 (DIO9/ON_SLEEP)

Sets or displays the DIO9/ON_SLEEP configuration (pin 13).

Parameter range

0, 1, 3 - 5

Parameter Description

0 Disabled

ON/SLEEP output

3 Digital input

4 Digital output, default low

5 Digital output, default high

Default

P0 (DIO10/PWM0 Configuration)

Sets or displays the PWM/DIO10 configuration (pin 6).

This command enables the option of translating incoming data to a PWM so that the output can be

translated back into analog form.

Parameter range

0 - 5

Parameter Description

0 Disabled

1 RSSI PWM0 output

2 PWM0 output

3 Digital input

4 Digital output, low

5 Digital output, high

Default

P1 (DIO11/PWM1 Configuration)

Sets or displays the DIO11 configuration (pin 7).

Default Chapter2
