DigiDesign D-Command - XMON Back Panel

D-Command Guide12
XMON Back Panel
The back panel of the XMON interface includes connectors for all external analog audio inputs and outputs for D-Command. See
“Audio Connections” on page 19.
Figure 5. XMON back panel
Cue Inputs
Cue Outputs
Main Inputs Surround Inputs Stereo Inputs
Main Outputs Alt Outputs Talkback/ Meter Calibration Control Surface AC Power
Listenback/
Utility
Screws
