4.1.6 Programming example with
the Uhlenbrock™intelibox
Programming the base address (Out 1).
1. Connect the DK50018 to the intellibox's main channel output.
2. Select "Keyboard Mode" on the control panel by pressing the [Mode] buon unl
"Keyboard" appears on the display.
3. Now select the base address by pressing the [Menu] buon.
4. Press the DK50018 programming buon so that the yellow LED lights up.
5. Switch the selected address on your Intellibox. The yellow LED on the DK50018 should
ash on and o, which means that the starng address is stored in memory.
