3–3Cabling the Site
Figure 3–1: Standard Ethernet Coaxial Cable Connection
LKG-5570-91I
Standard Ethernet
coaxial cable
Transceiver cable
Etherjack
Transceiver cables
DELNI
DECserver 700
Transceiver
DECserver 700
DECserver 700
