3–15Cabling the Site
3.6 Installing the DECserver 700 in a Rack
You can rack mount the DECserver 700 any one of four ways (Table 3–5) depending
on how you install the brackets.
Table 3–5: Installing the DECserver 700 Brackets
DECserver 700 Installation Bracket Installation
1. Flush with rear facing outward Flush with rear
2. Recessed 2.54 cm (1 in) with rear facing outward Forward 2.54 cm (1 in) from rear
3. Flush with front facing outward Flush with front
4. Recessed 2.54 cm (1 in) with front facing outward
Forward 2.54 cm (1 in) from rear
Figure 3–7 shows how to install the brackets in order to recess the DECserver 700.
Figure 3–8 shows how to remove the brackets.
CAUTION
The DECserver 700 can be wall mounted. If the DEC-
server is installed on a wall, the DECserver 700 must be
installed with the port connectors pointing up or point-
ing down. Digital Equipment Corporation does not sup-
ply wall mounting hardware for the DECserver 700.
