3–4 Site Preparation and Maintenance
3.2.2 Installing the 10BaseT Ethernet Cables and Devices
You can connect the DECserver 700 to a DETPR (Figure 3–2) by using:
• BN24F cable for local wiring requiring crossover
• BN25G cable for pin-to-pin building wiring
Figure 3–2: 10BaseT Ethernet Connection
LKG-5571-91I
Transceiver cable
BN24F cable
DETPR
Standard Ethernet coaxial cable
Transceiver
BN24F cable
BN25G cable
(Building wiring
pin-to-pin)
Wallplate
DECserver 700-08
DECserver 700-08
