Connector and Cable Pin Descriptions
This chapter describes the pins of the DECserver 700 hardware connectors and the
cables used to interface to the DECserver 700 hardware. Wiring diagrams of the indi-
vidual cables are included to help you in troubleshooting and cable building.
4.1 Connector Pin Descriptions
This section describes the pins for the following DECserver 700 connectors:
• Standard Ethernet/IEEE 802.3 transceiver interface
• 10BaseT Ethernet/IEEE 802.3 transceiver interface
• DECserver 700-08 serial port connectors
• DECserver 700-16 serial port connectors
