3–8 Site Preparation and Maintenance
Figure 3–5: DEMPR ThinWire Connection
LKG-3153-91I
DEMPR
DECrouter 250
VAXstation 2000
ThinWire Ethernet cables
DECrouter 250
DECrouter 250
Connector
T-connector
Terminator
MAU
DECserver 700-08 DECserver 700-08
