7–10 Site Preparation and Maintenance
7.8 Network Activity LED
Table 7–2: Network Activity LED
Ethernet Selected Connection Status LED Display
10BaseT Open/incorrectly terminated OFF
Correctly terminated / no network activity ON
Correctly terminated / network activity FLASHING (rate
independent of network
activity)
Standard Ethernet Open OFF
Correctly connected / no network activity OFF
Correctly connected / network activity Flashing or ON,
depending on network
activity
