1–5Hardware Overview
Table 1–3: Network Activity LED
Ethernet
Selected
Connection Status LED Display
10BaseT Open/incorrectly terminated
Correctly terminated / no network activity
Correctly terminated / network activity
OFF
ON
Flashing (rate independent of
network activity)
Standard Ethernet Open
Correctly connected / no network activity
Correctly connected / network activity
OFF
OFF
Flashing or ON, depending
on network activity
Table 1–4: DECserver 700 Connectors
Connector
Description
Serial port connectors
(DECserver 700-08)
These eight 25-pin male D-connectors connect EIA-232-D
devices to the DECserver 700.
Serial port connectors
(DECserver 700-16)
These 16 female MJ8 connectors connect data-lead de-
vices to the DECserver 700.
Standard Ethernet connector This single 15-pin female D-connector connects to a stan-
dard Ethernet/IEEE 802.3 local area network using a
transceiver cable.
10BaseT Ethernet connector This single female MJ8 connector connects to a 10BaseT
Ethernet/IEEE 802.3 local area network.
Power cord receptacle The DECserver 700 power cord plugs into this receptacle.
