Connector and Cable Pin Descriptions 4–7
Table 4-1 (Cont.): Cable Connections
Cable Type Description
BN25G MP8 to MP8 Equipment Cable The BN25G is a four twisted-pair cable with
standard 8-pin modular plugs. Can be used
with the DECserver 700-16.
H8584-AA MP8 to MMJ Adapter The H8584-AA MP8 to MMJ adapter is used
to convert a serial port to a DECserver 300
terminal server configuration. Can be used
with the DECserver 700-16.
H8585-AA MJ8 to DB9 Null-Modem
Adapter
The H8585-AA MJ8 to DB9 null-modem
adapter is used to convert the serial port to a
DB9 female connector for asynchronous con-
nection to a PC port. Can be used with the
DECserver 700-16.
BN24H MP8 to MP6 Office Cable The BN24H is a three twisted-pair cable with
a standard 8-pin modular plug on one end and
a 6-pin modular plug on the other. Can be
used with the DECserver 700-16.
H8585-AB MJ8 to DB25 Modem Adapter The H8585-AB MJ8 to DB25 low speed mo-
dem adapter is used to convert a serial port to
the DB25 configuration. Can be used with the
DECserver 700-16.
H8585-AC MJ8 to DB25 Modem Adapter
The H8585-AC MJ8 to DB25 high speed mo-
dem adapter is used to convert a serial port to
the DB25 configuration. Can be used with
the DECserver 700-16.
NOTE
Adapters H8585-AB and H8585-AC are not for connection to public networks in
Sweden, Germany, or Japan.
For a list of signals supported by the DECserver
700-16, refer to Section 3.3.
