2.4 Specifications
CPU:
Specification
CPU
AMD ELAN520 – 133MHz
Compatibility: 8086 – Pentium
1. Level Cache: 16k data and 16k code
2. Level Cache: None
Socket: BGA
Clock 133MHz
FSB 33MHz
Powermanagement None
FPU: Integrated
Chipset:
Specification
Nordbridge AMD ELAN520
Southbridge AMD ELAN520
LAN 82C559 INTEL
Audio Not on board
Firewire IEEE1394 Not on board
Video CT69000 (2Mbyte)
Framegrabber/TV-Input
Not on board
Memory
Specification
Main Memory SDRAM, 32Bit, up to 128Mbyte in two SODIMM144 socket
Flash-BIOS 256kByte Flash
Setup EEPROM 2kByte for CMOS-backup in batterless applications
Flash-VideoBIOS: Serial-Flash
Video RAM Separate 2Mbyte
Video controller
Specification
Controller CT69000
Videomemory 4Mbyte
Channel 1 CRT VGA up to 1248 x 1024 pixels
Channel 2 TFT
Bootup-Resolution 640 x 480 / 800 x 600 / 1024 x 768 VGA bios depending
2D-Grafic Integrated accelerator
3D-Grafic Not available
Direct-X Version Not available
PnP Not available
