3.1 Bus levels
The bus currents are as follows:
Output Signals: IOH: IOL:
D0 - D16 8 mA 8 mA
A0 - A23 8 mA 8 mA
MR, MW, IOR, IOW, RES, ALE, AEN, C14 8 mA 8 mA
DACKx, DRQx, INTx, PSx, OPW 8 mA 8 mA
Output Signals: Logic Family: Voltage:
ABT-Logic ABT-Logic
Input Signals: ViH (min.) = 2.15 V Vil (max.) = 0.85 V
