4.3.5 Speaker interface
One of the board's CPU device provides the logic for a PC compatible speaker port. The speaker logic signal
is buffered by a transistor amplifier, and provides approximately 0.1 watt of audio power to an external 8 ohm
speaker. Connect the speaker between VCC and speaker output to have no quiescent current.
4.3.6 LAN Interface:
82559 82559ER 82551 82551ER 82540EM
Product Features
Data Rates (Mb/s) 10/100 10/100 10/100 10/100 10/100/1000
I/O Interface 32-bit PCI 32-bit PCI 32-bit PCI 32-bit PCI 32-bit PCI
Bus Frequency 33Mhz 33Mhz 33Mhz 33Mhz 66Mhz
Package (dimensions) 15x15mm 15x15mm 15x15mm 15x15mm 15x15mm
Pin Count 196 pin TBGA 196 pin TBGA 196 pin TBGA 196 pin TBGA 196 pin BGA
TCP, UDP, IPv4 Checksum Offload Yes - Yes Yes Yes
Wired for Management support Yes - Yes - Yes
PXE support Yes 3rd party only Yes 3rd party only Yes
Alert on LAN 2 Yes - - - -
ASF (Tx and Rx alerting) - - Yes - Yes
SMBus interface Yes - Yes - Yes
Wake on LAN Yes - Yes - Yes
Magic Packet Yes - Yes - Yes
Remote power up support Yes - Yes - Yes
32-bit PCI/CardBus interface Yes - Yes - -
Modem Interface Yes - Yes - -
VLAN support Yes - Yes - Yes
Device ID 1229 1209 1229 1209 100E
Available in Ext. Temp (-25-85C) - Yes - TBD -
82559 82559ER 82551 82551ER 82540EM
Software/Driver Support
ANS support (link aggregation, failover) Yes - Yes - Yes
NDIS 3, 4 Yes Yes Yes Yes Yes
NDIS 5 (Win2K, WinXP) Yes - Yes - Yes
WinXP Embedded Yes Yes Yes Yes Yes
WinNT Embedded Yes Yes Yes Yes Yes
WinCE 2.12 Yes Yes Yes - Yes
WinCE 3.0 Yes Yes Yes Yes Yes
WinCE 4.0 Yes Yes Yes Yes Yes
Linux Yes - Yes Yes Yes
Solaris Yes - Yes - Yes
Netware Yes - Yes - Yes
SCO OpenServer Yes - Yes - Yes
FreeBSD Yes* Yes* Yes* TBD* Yes*
NetBSD Yes* Yes* Yes* TBD* Yes*
VxWorks Yes* Yes* Yes* Yes* Yes*
BSD/OS - - TBD* TBD* TBD*
pSOS Yes* Yes* - - -
QNX Yes* Yes* TBD* TBD* TBD*
*through 3rd party ISV
