DIGITAL-LOGIC AG MSM586SEN/SEV Manual V1.5E
99
When video redirection is enabled (option NOVIDEO not active), the BIOS will skip the initialization of both
ISA and PCI VGA cards. The BIOS thereby comes up much quicker. Using the keyword DUALVIDEO will
enable possible VGA cards as well and display video output on both the real video card and on the remote
machine. This allows hardware engineers to debug vga controller problems.
The BIOS will not warn for missing keyboards as soon as remote keyboard is enabled.
You can leave REMHOST by pressing the left SHIFT and STRG keys simultaneously.
11.1.2 Remote enabler
To enable the remote function, one has to make a hardware switch as follows:
• Pin4 (DTR) and pin 9 (RI) have to be bridged on the target PC
• Leave pin 9 unconnected (open) from the host PC
11.1.3 Cable Definition (DSUB-9pin-female)
The wiring of the serial null-modem cable is as follows:
PC1 (Host) PC2 (Target)
Signal Name DSUB-Pin Number
