DIGITAL-LOGIC AG MSM586SEN/SEV Manual V1.5E
76
6.7 Memory 69000 Mono STN-DD panels
Hor.
Resol.
Vert.
Resol.
Color
bpp
Refr.
Hz
DCLK
Mhz
MEM
kByte
Cursor
kByte
FB/C
kByte
FB/M
kByte
Video
Input
kByte
Total
with
Video
Total
w/o
Video
640 480 8 60 25.175
300 4.2 0 38 300 642 342
640 480 8 72 31.500
300 4.2 0 38 300 642 342
640 480 8 75 31.500
300 4.2 0 38 300 642 342
640 480 8 85 36.000
300 4.2 0 38 300 642 342
640 480 16 60 25.175
600 4.2 0 38 300 942 642
640 480 16 72 31.500
600 4.2 0 38 300 942 642
640 480 16 75 31.500
600 4.2 0 38 300 942 642
640 480 16 85 36.000
600 4.2 0 38 300 942 642
640 480 24 60 25.175
900 4.2 0 38 300 1242 942
640 480 24 72 31.500
900 4.2 0 38 300 1242 942
640 480 24 75 31.500
900 4.2 0 38 300 1242 942
640 480 24 85 36.000
900 4.2 0 38 300 1242 942
800 600 8 60 40.000
469 4.2 0 59 300 832 532
800 600 8 72 50.000
469 4.2 0 59 300 832 532
800 600 8 75 49.500
469 4.2 0 59 300 832 532
800 600 8 85 56.250
469 4.2 0 59 300 832 532
800 600 16 60 40.000
938 4.2 0 59 300 1300 1000
800 600 16 72 50.000
938 4.2 0 59 300 1300 1000
800 600 16 75 49.500
938 4.2 0 59 300 1300 1000
800 600 16 85 56.250
938 4.2 0 59 300 1300 1000
800 600 24 60 40.000
1406 4.2 0 59 300 1769 1469
800 600 24 72 50.000
1406 4.2 0 59 300 1769 1469
800 600 24 75 49.500
1406 4.2 0 59 300 1769 1469
800 600 24 85 56.250
1406 4.2 0 59 300 1769 1469
! Means not possible resolution with the 4Mb Video RAM
