DIGITAL-LOGIC AG MSM586SEN/SEV Manual V1.5E
77
7 DESCRIPTION OF THE CONNECTORS
Flat cable
• 44pin IDE is: IDT Terminal for Dual Row (2.00mm grid) and 1.00mm flat cable
• All others are: IDT Terminal for Dual Row 0.1" (2.54mm grid) and 1.27mm flat cable
Connector Texture Pin Remarks
J02 FDD micro 26 FCC micro
J04 COM1 internal ELAN 2x5 2.54mm
J07 LCD / VGA connector 2x20 2.54mm
J22 HDD primary 2x22 2mm
J27 Utility; PS/2- mouse- keyboard; reset;
speaker
2x5 2.54mm
J40 PC104 bus 104 2.54mm
J41 COM2 internal ELAN 2x5 2.54mm
J43 LAN 4 2.54mm
J48 Power supply / IrDA 8 2.54mm
J49 COM D SUPER I/O (2x10) 2.54mm
J50 COM C SUPER I/O (2x10) 2.54mm
J55 DDC (not assembled) 2 2.54mm
J60 Ext. HDD Led 2 2.54mm
B1 Battery Lithium 3.6V 2
P1 LPT 2x13 2.54mm
U95 SODIMM socket 144
U96 Compact card holder, typ1 50
U112 DOC2000 IC socket 2x16 2.54mm
X2 JTAG connector 2x6 2mm
X1 ELAN520 spare (not assembled) 2x15 2mm
X3 LAN LED connector 3 2.54mm
