Connecting and Removing Cables and Adapters 5-15
Removing the Cables
Removing Cables from the AUI 10BASE-T Port Adapter
Figure 5-13 shows how to remove cables from the 15-Pin AUI 10BASE-T port
adapters.
Figure 5-13: Removing AUI 10BASE-T Port Adapter Cables
To remove the cable from the adapter, complete the following steps:
Step Action
1 Press in the release tab on the 10BASE-T connector (1), remove the
connector from the port on the AUI adapter (2).
2 Remove the other end of the cable from the repeater (Optional).
3505-32
