Digital Projection E-Vision Series User Manual

DLP Projector—User’s Manual
OSD Menu Overview
Use the following illustration to quickly find a setting or determine the range for a setting.
Settings 1
Off, On
Blank, Red, Green, Blue, White
Off, On
Off, On
3D
3D Sync Invert
3D Format
Hue
Saturation
English, Français, Español, Deutsch, Português, 簡体中文, 繁體中文, Italiano,
Svenska, Nederlands, Suomi, Ελληνικά, Norsk, Polski, Русский, 한국어, 日本語,
اﻟﻌﺮﺑﻴﺔ , Magyar, ไทย, Türkçe, Čeština, Việt, ﻓﺎرﺳﯽ , תירבע
Off, On
Gain
1.8, 2.0, 2.2, 2.4, B&W, Linear
Off, On
Hue
Saturation
Gain
Hue
Saturation
Gain
Hue
Saturation
Gain
Hue
Saturation
Gain
Hue
Saturation
Gain
Red
Green
Blue
Reference Input Source Select (IR/Keypad)
Off, On
None, Grid, White, Red, Green, Blue, Black
Settings 2
Center, Down, Up, Left, Right
0%, 25%, 50%, 75%, 100%
Off, Low Power, Power On by LAN, VGA Out
00-98
Normal, High
Display Mode
Brightness
Auto Image
Computer
Contrast
Advanced
Color Manager
Source
Aspect Ratio
Projection
Audio
Digital Zoom
Keystone
Advanced 1
Advanced 2
Auto Source
Auto Power On
No Signal Power Off
Status
Reset All
Lamp Mode
Advanced 1
Advanced 2
Volume
Security Lock
Blank Screen
Splash Logo
Keypad Lock
3D Setting
Horizontal Position
Vertical Position
Frequency
Tracking
Red
Language
Closed Captioning
Green
Blue
Cyan
Magenta
Yellow
White
Source
Mute
Test Pattern
H Image Shift
V Image Shift
Off, On
Menu Position
Translucent Menu
Low Power Mode
Lamp Hour Reset
Projector ID
Fan Speed
Off, On
Sleep Timer
Source Filter
ECO , Normal
DVI
HDMI
DisplayPort
VGA1
VGA2
Normal, Rear, Ceiling, Rear+Ceiling
Fill, 4:3, 16:9, Letter Box, Native, 2.35:1
Presentation, Bright, Game, Movie, TV, sRGB, BlackBoard, User1, User2
Off, On
Frame Sequential, Top/Bottom, Side-By-Side, Frame
Packing (3D FramePacking HDMI source only)
Off, DLP-Link, IR
Disable, Enable
Disable, Enable
Disable, Enable
Disable, Enable
Disable, Enable
Auto Sync Off, On
BNC
Component Video
S-Video
Composite Video
Disable, Enable
Disable, Enable
Disable, Enable
Disable, Enable
Active Source
Video Information
Lamp Hours(ECO , Normal, Abnormal)
Serial Number
Software Version
Network State
Network
DHCP
IP Address
Subnet Mask
Gateway
DNS
Apply
Connect, Disconnect
Off, On
0~255, 0~255, 0~255, 0~255
0~255, 0~255, 0~255, 0~255
0~255, 0~255, 0~255, 0~255
0~255, 0~255, 0~255, 0~255
OK / Cancel
Screen Capture
Projection Angle Caution
Off, On
— 24 —

Digital Projection E-Vision Series Specifications

General

Dimensions	Varies by model
Technology	DLP
Light Source	Laser
Light Source Life	Up to 30, 000 hours (laser)
Throw Ratio	Varies by model
Projection Size	Varies depending on lens and distance
Input Lag	Varies by model
Color Gamut	Varies by model, typically Rec.709
HDR Support	Yes
3D Support	Yes
Lens Shift	Vertical and Horizontal
Keystone Correction	Yes
Inputs	HDMI, DisplayPort, DVI, VGA
Weight	Varies by model (typically 20-50 lbs)
Power Consumption	Varies by model (typically 300-500W)
