APPENDIX I
RS-232C Protocol
RS232 Setting
Baud rate:
9600
Parity check: None
Data bit: 8
Stop bit: 1
Flow Control None
Control Command Structure
Header code Command code Data code End code
HEX Command Data 0Dh
ASCII ‘V’ Command Data CR
Operation Command
Note:
XX=00-98, projector's ID, XX=99 is for all projectors
Return Result P=Pass / F=Fail
n: 0:Disable/1: Enable/Vaule(0~9999)
Command Group 00
ASCII HEX Function Description Return Result
VXXS0001 56h Xh Xh 53h 30h 30h 30h 31h 0Dh Power On P/F
VXXS0002 56h Xh Xh 53h 30h 30h 30h 32h 0Dh Power Off P/F
VXXS0003 56h Xh Xh 53h 30h 30h 30h 33h 0Dh Resync P/F
VXXG0004 56h Xh Xh 47h 30h 30h 30h 34h 0Dh Get Lamp Hours Pn/F
VXXS0006 56h Xh Xh 53h 30h 30h 30h 36h 0Dh System Reset P/F
VXXG0007 56h Xh Xh 47h 30h 30h 30h 37h 0Dh Get System Status
0:Reset
1:Standby
2:Operation
3:Cooling
Pn/F
VXXG0008 56h Xh Xh 47h 30h 30h 30h 38h 0Dh Get F/W Version Pn/F

Digital Projection E-Vision Series Specifications

General

Dimensions	Varies by model
Technology	DLP
Light Source	Laser
Light Source Life	Up to 30, 000 hours (laser)
Throw Ratio	Varies by model
Projection Size	Varies depending on lens and distance
Input Lag	Varies by model
Color Gamut	Varies by model, typically Rec.709
HDR Support	Yes
3D Support	Yes
Lens Shift	Vertical and Horizontal
Keystone Correction	Yes
Inputs	HDMI, DisplayPort, DVI, VGA
Weight	Varies by model (typically 20-50 lbs)
Power Consumption	Varies by model (typically 300-500W)
