GENETX Row
The GENETX row is where amp and cabinet models are selected for the current preset. It is also
where the Warp function resides allowing GeNetX
™
warping between the two amp models. When the
GENETX row is selected,the Knobs and Status Button perform the following functions:
STATUS BUTTON
Selects between Amp Channel 1 (Green) and Amp Channel 2 (Red) and lets you hear each channel
independently, or if a Warped state (Yellow) between both channels exists,this button selects it and
lets you hear the warped amp. The Status Button’s LED will light Green,Red,or Yellow depending on
which channel is selected.
KNOB 1
Selects the Channel 1 (Green) amp model and the LED for Knob 1 is lit green.
KNOB 2
Selects the Channel 1 (Green) cabinet model and the LED for Knob 2 is lit green.
KNOB 3
Warps the Channel 1 and Channel 2 amp and cabinet models together. Setting this knob to its
minimum position selects Channel 1’s amp and cabinet only and the LED for Knob 3 is lit green.
Setting this knob to its maximum position selects Channel 2’s amp and cabinet only and the LED for
Knob 3 is lit red. Setting Knob 3 to any other position selects a warped state, a combination of
Channel 1 and 2’s amp and cabinet models and the LED will be lit yellow.
KNOB 4
Selects the Channel 2 (Red) amp model and the LED for Knob 4 is lit red.
KNOB 5
Selects the Channel 2 (Red) cabinet model and the LED for Knob 2 is lit red.
