DigiTech JAMMAN User Manual

70
Digital
A/D/A Conversion: 24-bit
Sampling Frequency: 44.1 kHz
Loop File Format: 44.1 kHz, 16-bit (stereo), uncompressed
WAV file
USB: 2.0 High Speed (USB 1.1 compatible)
Connector Type: 4-pin Type B
Max. Individual Loop Time: 10 minutes
Internal Memory Capacity: Over 35 minutes total loop time (up to
99 loops total)
External Memory Type: SD/SDHC up to 32GB (optional)
External Memory Capacity: Over 16 hours (10.6MB/minute) of
recording time, when using 16GB or
larger SDHC card (up to 99 loops total)
Inputs/Outputs
Left(Mono)/Right Inputs
Connector Type: 1/4” Unbalanced (Tip-Sleeve)
Input Impedance: 500 kΩ Mono/1 MΩ Stereo
Unity Gain Input to Output: 4 dBu DFS
Left(Mono)/Right Outputs
Connector Type: 1/4” Unbalanced (Tip-Sleeve)/Balanced
(Tip-Ring-Sleeve)
Output Impedance: 1 kΩ Unbalanced/ 2 kΩ Balanced
Maximum Output Level: 10 dBu DFS
Playback Unity Gain: Loop Level knob set to 12 o’clock position
Expression Input
Connector Type: 1/4” Stereo (Tip-Sleeve) – compatible with a
(Tip-Sleeve) Expression / passive Volume Pedal
Footswitch Input
Connector Type: 1/4” Stereo (Tip-Ring-Sleeve), compatible
with optional DigiTech
®
FS3X 3-button
footswitch
Specifications

DigiTech JAMMAN Specifications

General

Technology	Digital
MIDI	No
Type	Looper
Memory	Internal memory for loop storage
Power Supply	9V DC
Outputs	1 x 1/4" Mono
