18
Left (Mono) Input 1.
Connect your instrument, additional pedal, or an amp effects send to
this jack. Signals are heard at both outputs when only the Left (Mono)
jack is used.
2. Right Input
Connect a second input to this jack for stereo operation. Left and Right
inputs are processed separately through the stereo delay and looper
effects and then fed to the Left and Right outputs to keep true stereo
separation between channels.
Tails On/Off Switch3.
This switch allows the delay repeats to continue being heard after the
effect is bypassed, or cuts them off immediately. When the Tails Switch
is set ON, delay repeats will continue to be heard until they decay
completely. When the Tails Switch is OFF, delay repeats are cut off
immediately when the effect is bypassed.
Left (Mono) Output4.
Connect this output to the input of a single guitar amplifier, another
pedal input, or amp effects return.
Guided Tour - Rear Panel
1 2 3 4 5 6 7 8 9 10 11
