2. Installation
This chapter describes the function of the management switch components
and shows how to install it on the desktop or shelf. Basic knowledge of
networking is assumed. Read this chapter completely before continuing.
1.1.Product Description Overview
These product is a L2 management switch which supports 802.1Q VLAN,
QoS, 802.1d / 1w/ 1s Spanning Tree Protocol, 802.1x, Port Security, Port
Mirroring, IGMP Snooping, SNTP, Storm Control, Rate Control, SNMP etc.
features.
1.2.Switch Front and Rear Panel
8-Port 100BaseTX + 2 Gigabit combo Layer 2 Management Switch with 8 PSE
port embedded 100W PoE power budget
The front panel of this switch has 8 10/100 Mbps copper ports at the left with
2 shared Gigabit SFP slots at the right. The product name indicates at the top
on the right. Figure 2.2.6a shows a front panel of the switch. The rear panel
has a power and console connector, and Figure 2.2.6b shows a rear panel of
the switch. Table 2.2.6c shows the port function of the switch.
Figure 2.2.6a Front Panel
Figure 2.2.6b Rear Panel
Power
Table 2.2.6c Port Function
Port Function
Power
This is where you connect the DC power adapter.
Layer 2/2+ Management Switch Series 6
