DINGLI JCPT DCS Series User Manual

培训手册 Training Manual
参数调整 Parameter Adjustment
JCPT- DCS
www.cndingli.com
4-14
highest. The up limit switch, descend delay and outdoor limitation are automatically off when calibration.
The functions will come back after quit the screen）
剪叉平台在最低点校验(The lowest postion calibration)
将平台下降到最下限位置，观察 Analog 电位计的模拟量是否正常变化。(Check the
analog number when the platform is in stowed position)
实时电位计模拟量,系统内部需要激活电位计功能；
(The analog number of the potentiometer)
退出电位计检验界面；
(Quit the calibration)
将电位计实际 Analog 参数发送给 ECU，检验为最低位值；
(Confirm the analog and send to ECU)
保存发送到 ECU 的数据，如果未按此键，系统断电时，参数
不被保存；(Save)
剪叉平台在最高点校验(The highest postion calibration)
将平台起升到最上限位置，观察 Analog 电位计的模拟量是否正常变化，为了保证电位
计的跳变对系统的影响，在平台达到油缸最大位置时，适当下降一定位置，再保存参
数。(Check the analog number when the platform is in fully elevated position)
