Before installation
• Check that the maximum oil pressure is lower than the maximum value indicated on the sensor datasheet (4000 psi = 280 bar).
• Remove the pressure in the hydraulic circuit; this can be done in two ways:
A. Lower the forks to their maximum
andmove forward.
Make sure the chain is loose.
B. Place the forks on a stable object.
Make sure the chain is loose.
Kit installation
