8
TECH_MAN_ENG_LTP
3. Fixing bracket for the indicator in the cabin
Bracket for horizontal adjustment during installation.
2. Pressure sensor
Stainless steel sensor, IP65 protection rating and hydraulic connector with 1/4 inch parallel PSB female.
Sensor dimensions: length: 73.5 mm; diameter: 24.5 mm.
4. Reference stickers
Stickers used to identify the height range of the forks within which the weighing operations are to be carried out.
To be applied to the structure of the forklift.
