50
© 2009 Directed Electronics. All rights reserved.
2-11 FACTORY ALARM DISARM PULSES—SINGLE, DOUBLE: Selectable for a
single or double-pulse for the vehicle’s factory alarm disarm input requirements.
2-12 AUX 2 VALIDITY(1)/LATCHED(2)/LATCHED RESET WITH IGNI-
TION(3)/30(4), 60(5) and 90(6) SEC TIMED OUTPUT:
This wire provides a (-) 200mA output whenever the transmitter button(s) control-
ling AUX 1 is pressed. This output can be programmed to provide the following
types of outputs:
Validity: Output that will send a signal as long as the transmission is re-•
ceived.
Latched: Output that will send a signal when the AUX button is pressed and •
will continue until the same button(s) is pressed again.
Latched, reset with ignition: Similar to the latched output, this type of output •
turns on the first time the AUX button is pressed and turns off the next time
the same button is pressed. This type of output additionally stops and resets
whenever the ignition is turned on and then off.
30-second timed: Output that will send a continuous signal for 30 sec-•
onds.
Note: All auxiliary channel timed outputs can be programmed using the
Bitwriter® (1-90 seconds).
2-13 AUX 2 LINKING NONE(1)/ARM(2), DISARM(3), REMOTE START(4):
When programming to validity or timed output this can be programmed to acti-
vate when arming or disarming (or remote starting) with the transmitter.
2-14 AUX 3 VALIDITY(1)/LATCHED(2)/LATCHED RESET WITH IGNI-
TION(3)/30(4),60(5) and 90(6) SEC TIMED OUTPUT:
AUX 3 can be programmed for these output configurations. The unit is set to the
default validity output. To change the configuration, use the two-chirp setting to
toggle through the different configurations. Refer to feature 2-12 for additional
detail.
2-15 AUX 3 LINKING NONE(1)/ARM(2), DISARM(3), REMOTE START(4): Re-
fer to feature 2-13 for additional detail.
